The MacBook Pro 16″ is Apple’s largest pro laptop — Liquid Retina XDR mini-LED in M-series, 99.6Wh battery (the largest cell-volume Apple ships in a laptop), six-speaker system. Multiple generations: Intel 16″ (2019-2020 — last Intel Pro), M1 Pro/Max (2021), M2 Pro/Max (2023), M3 Pro/Max (2023), M4 Pro/Max (2024). We service all.
Models We Service
Every generation we currently service:
| Model | Year | Common faults | Service status |
|---|---|---|---|
| MacBook Pro 16″ Intel (2019-2020) | Last Intel 16″ | Battery, GPU, board | Yes |
| MacBook Pro 16″ M1 Pro/Max (2021) | First M-series 16″ | Battery, screen, MagSafe | Yes |
| MacBook Pro 16″ M2 Pro/Max (2023) | M2 refresh | Same | Yes |
| MacBook Pro 16″ M3 Pro/Max (2023) | M3 line | Same | Yes |
| MacBook Pro 16″ M4 Pro/Max (2024) | Current — Thunderbolt 5 | Same plus TB5 | Yes |
Common Issues & How We Fix Them
Battery service (large 99.6Wh cell)
Largest battery in any Apple laptop. Replacement: $580-$680 fitted (slightly higher than 14″ due to cell size).
Liquid Retina XDR mini-LED screen
$1,400-$1,800 fitted. Largest panel in MacBook line.
16″ Intel GPU failure (2019-2020)
Some Intel 16″ Pros had discrete Radeon Pro GPU thermal issues. BGA reflow / reball: $580-$880.
16″ Intel hinge stress
Heavy lid + 16″ panel. Hinge mounting wear at 4-5 years. Re-tension or hinge cluster: $280-$580.
MagSafe 3 + 3× USB-C/TB4 + HDMI + SD
Most ports of any MacBook. Each replaceable at $280-$480.
Liquid damage
Apple refuses. We accept. Ultrasonic clean.
16″ speaker system service
Six speakers + force-cancelling woofers. Voice-coil rattle service: $280-$580.
Thunderbolt 5 (M4 only)
M4 16″ Thunderbolt 5 diagnostics.
Our Repair Process
- Free quote + warranty check.
- Drop-off or courier.
- Workshop turnaround 1-5 days.
- 90-day warranty.
Frequently Asked Questions
MacBook Pro 16" Repair faults we repair every week
M1/M2/M3 99.6Wh battery swelling
Symptom: Trackpad lift, case bulge, sudden shutdowns after 18-24 months
How we fix it: Remove bottom case, disconnect battery connector, fit new 99.6Wh OEM-spec cell with calibrated BMS, reassemble and run Apple diagnostics.
Repair or replace? repair
Intel 16-inch discrete GPU thermal failure
Symptom: Kernel panics, black screen, fan ramp under light load on 2019-2020 models
How we fix it: BGA station reflow or reball of Radeon Pro chip, replace thermal pads and paste, stress test under Geekbench Metal.
Repair or replace? repair
Liquid Retina XDR hinge mounting wear
Symptom: Screen wobble, uneven lid closure, creaking at 4-plus years
How we fix it: Replace hinge cluster assembly including torque brackets and display cable, realign lid and torque to spec.
Repair or replace? repair
MagSafe 3 connector fracture
Symptom: Intermittent charging, visible pin damage on 2021+ models
How we fix it: Desolder damaged MagSafe 3 module from I/O board, fit new module and test full 140W negotiation.
Repair or replace? repair
Six-speaker voice coil rattle
Symptom: Distorted bass at moderate volume, visible cone damage on force-cancelling woofers
How we fix it: Remove speaker array, replace affected voice-coil assemblies, recalibrate with Apple Configurator audio test.
Repair or replace? repair
M4 Thunderbolt 5 port failure
Symptom: No 80Gbps link or 40Gbps fallback only on right-side ports
How we fix it: Replace Thunderbolt 5 controller on logic board or entire I/O board depending on damage pattern, verify with external 8K display chain.
Repair or replace? Depends
MacBook Pro 16" Repair price guide
| Repair | Indicative price | Typical turnaround |
|---|---|---|
| 99.6Wh battery replacement | $580-$680+ | 2-3 days |
| Liquid Retina XDR screen assembly | $1,400-$1,800+ | 2-4 days |
| Intel GPU BGA reflow/reball | $580-$880+ | 3-5 days |
| Hinge cluster replacement | $280-$580+ | 1-3 days |
| MagSafe 3 module replacement | $280-$480+ | 1-2 days |
| Six-speaker array service | $280-$580+ | 2-3 days |
| Thunderbolt 5 diagnostics + repair | from $149 | 2-5 business days |
| Ultrasonic clean after liquid spill | from $220 | 2-4 days |
Prices are indicative only — every job is confirmed with a free, no-obligation quote after diagnosis. No Fix, No Fee.
MacBook Pro 16" Repair — your questions answered
How much does a new battery cost for a MacBook Pro 16 inch?
Replacement of the 99.6Wh cell in any M-series 16-inch model is typically $580-$680 including fitting and calibration. The larger cell volume raises the part price compared with 14-inch units. We image your drive first and run full diagnostics before quoting.
Can you fix the screen on a MacBook Pro 16 inch?
Yes, we replace the full Liquid Retina XDR mini-LED assembly for $1,400-$1,800 fitted. The 16-inch panel is the largest Apple currently ships and requires careful lid alignment after installation. Turnaround is usually two to four business days.
Is the Intel MacBook Pro 16 worth repairing in 2025?
The 2019-2020 Intel models remain serviceable for GPU reflows, hinge work and battery swaps. If your unit still meets your workload we can extend its life at a fraction of replacement cost. We always run a no-fix-no-fee diagnostic first.
Do you repair liquid damage on MacBook Pro 16 inch models?
We accept liquid-damaged 16-inch units and perform ultrasonic cleaning of the logic board and connectors. Success depends on how quickly the spill was addressed and which components were affected. A diagnostic quote is provided before any work begins.
How long does a MacBook Pro 16 inch repair usually take?
Most common jobs such as battery or hinge replacement finish in two to three days. Board-level work like GPU reflow or Thunderbolt 5 diagnostics can take three to five days. We offer workshop drop-off or courier collection across Australia.
